Flexible measurement placement
An external probe helps separate the measurement point from the main logger location.
CALIBRA / NB-IOT MONITORING
Put the probe
where it matters.
External-probe temperature monitoring. Connected to your team.
Measure at the point you need to understand while planning a suitable location for the logger itself. Calibra brings external-probe readings into ThermoCloud for visibility, configured notifications and historical review.
−55°C to +125°CPublished measurement range
NB-IoTCellular reporting
40,000Stored measurements
Up to 5 yearsFlyer battery-life specification
THE OPERATIONAL VALUE
Make measurements useful.
Useful temperature history
Recorded measurements and downloadable reports support trend review and excursion investigations.
Clearer daily oversight
Give designated users access to conditions through ThermoCloud rather than relying only on local observations.
WHERE CALIBRA FITS
Inside the monitored space.
In view of your team.
Refrigeration & freezer storage
Monitor a selected point inside suitable refrigerated equipment while keeping the logger in an appropriate operating environment.
Food storage & preparation environments
Build temperature records around defined storage points and agreed operational checks.
Laboratories & specialist storage
Place the probe at a relevant measurement location and review readings alongside your established quality procedures.
CONNECTED THROUGH NB-IOT
From measurement.
To informed action.
Measure
Capture conditions at the selected monitoring point. Sampling settings determine the measurement frequency.
Transmit
NB-IoT sends data over the cellular network to the Thermologix platform. Reporting depends on coverage and configuration.
Understand
Use ThermoCloud graphs, configurable limits, notifications and downloadable reports to review available readings.
Respond
Designated people investigate changes and follow your organisation’s operating and quality procedures.
CALIBRA.TMP / TECHNICAL INFORMATION
Know the device.
Plan with confidence.
Specifications below follow the supplied Thermologix flyer. Select the device revision, configuration and calibration appropriate for your application.
Download Calibra flyer- Probe measurement range
- −55°C to +125°C
- Accuracy: −10°C to +85°C
- Up to 0.5°C
- Accuracy: outer temperature bands
- 2°C from −55°C to −10°C and +85°C to +125°C
- Resolution
- 0.1°C
- Temperature drift
- <0.1°C/year
- Measurement interval
- 1 minute to 10 days, configurable; flyer default: 10 minutes
- Transmission interval
- 5 minutes to 10 days, configurable
- Memory
- 40,000 measurements
- Communication
- NB-IoT; CoAP protocol
- Bluetooth LE
- 2.4 GHz; up to 100 m line of sight for the local radio interface
- Battery
- 6300 mAh internal battery; operating life up to 5 years
- Dimensions & weight
- 124 × 60 × 26 mm; 170 g
- Firmware updates
- Over the air, with delta mechanism
GET THE FIT RIGHT
A useful deployment starts
with the right questions.
Match measurement to reporting
Sampling and transmission are separate settings. Agree the freshness your process needs; notification timing depends on data delivery and platform configuration.
Plan the installation
Confirm enclosure operating limits, mounting and protection requirements. The probe range is not the enclosure operating range.
Define the evidence
Discuss calibration scope, required accuracy and the records your quality team needs. Battery life depends on settings and operating conditions.
CALIBRA + THERMOCLOUD
Your environment.
A clearer picture.
Tell us what you need to measure, where it is stored and how your team will use the information.
Plan your Calibra deploymentYOUR MONITORING. WITH YOU.
Temperature visibility.
In your pocket.
Use the ThermoCloud app to view your connected sensors, check readings and receive temperature alerts on your phone.
